EM-P1: 6.56 inch Rugged Outdoor Phone Android 14 Helio G99

Name: EM-P1: 6.56 inch Rugged Outdoor Phone Android 14 Helio G99
Brand: Emdoor Information Co., Ltd.

Front 32MP Ultra HD lens 48MP Samsung Main Camera Capturing close-ups and landscapes

Waterproof material Remains unharmed in deep water Drop resistance up to 1.5 meters

720 × 1612 ultra-high definition 670 Nit high brightness 16.7 Million Colors

33W super fast charging Advanced battery management system Reverse charging mode

Helio G99 octa-core CPU Running on the latest Android 14 OS Experience impressive performance upgrade

Powerful speaker with Smart PA technology 100 lumen brightness flashlight Multi-satellite navigation for outdoor positioning

Get A Quote PDF Download

Android 14

IP68

GPS

High-capacity

camera

NFC

Bluetooth

wifi

Fingerprint

Features of EM-P1: 6.56 inch Rugged Outdoor Phone Android 14 Helio G99

Front 32MP Ultra HD lens 48MP Samsung Main Camera Capturing close-ups and landscapes
Waterproof material Remains unharmed in deep water Drop resistance up to 1.5 meters
720 × 1612 ultra-high definition 670 Nit high brightness 16.7 Million Colors
33W super fast charging Advanced battery management system Reverse charging mode
Helio G99 octa-core CPU Running on the latest Android 14 OS Experience impressive performance upgrade
Powerful speaker with Smart PA technology 100 lumen brightness flashlight Multi-satellite navigation for outdoor positioning

Six Views of EM-P1: 6.56 inch Rugged Outdoor Phone Android 14 Helio G99

Rugged Outdoor Phone

Specification of EM-P1: 6.56 inch Rugged Outdoor Phone Android 14 Helio G99

Rugged Outdoor Phone Tech Spec
Product Form	Rugged Phone & PDA 2-in-1
Dimension	170.280.714mm
Weight	Approximately 311g
Product Color	Black+Orange

CPU	MT6789 Octa-core, two cores of 2.2GHz + six cores of 2.0GHz 2A76 2.2GHz 6A55 2.0GHz
GPU	ARM G57 MC2
Memory	RAM 8GB LPDDR4X ROM 128GB UFS2.2 (Optional 8+256GB for bulk orders.)

Operating System	Android 14/ GMS

Display	Type: TFT Size: 6.56-inch 20:9 Resolution: 720*1612 Brightness: 670 Nit
Touch Pannel	PolyRainbow Cover, 5-point capacitive screen, Hardness above 7H, Scratch-resistant.

Camera	Front 32MP, Fixed Focus Rear Main Camera 48MP, Autofocus, Supports PDAF Rear Secondary Camera1 2MP Macro Rear Secondary Camera2 8MP Wide-angle
Flashlight	True Flash

Buttons	Power & Fingerprint 1 Volume + Key 1 Volume - Key 1 Barcode Scanning Key 2

Indicator Light	Indicator light *1, R/G dual-color light: Red constant when charging, green constant when fully charged (above 90%), red flashing when low battery (0-15%), off when discharging.

Audio	Speaker1 7Ω/1.5W Earphone1 Dual-MIC Motor*1 Audio SMART PA
Sensor	Light Sensor Proximity Sensor 3D Accelerometer Geomagnetic Sensor Gyroscope Gravity Sensor
Battery	Built-in Polymer Lithium-ion Battery 3.85V/5800mAh Battery Life：Approximately 17h24min（The default volume is 70dB, Default 300 nits brightness; Playing 1080P HD video) Charging time：Approximately 1h50min

WIFI	WIFI 802.11(a/b/g/n/ac)
Bluetooth	BT5.1
4G	GSM(B2/3/5/8)+WCDMA(B1/2/4/5/8)+TDD(B34/38/39/40/41)+FDD(B1/2/3/4/5/7/8/12/13/17/18/19/20//25/26/28A/28B/30/66)
GPS	Supports GPS/Beidou/Galileo/GLONASS Supports AGPS Cold Start Time:<60 seconds

I/O Interfaces	Type C *1(Charging/Data/Earphone/Reverse charging 6W)
	TF Card1 SIM Card 2
	TF Card1 SIM Card 2
	Pogo Pin (Charging) *1

Power Adapter	33W Fast Charge Adapter
Type-C Cable	Type-C Data Cable（1m）

Rugged Features	Drop Height: Withstands drops from 1.5 meters onto composite wood flooring, while powered on.
	Working temperature: -20 °C to 60 °C
	Storage temperature: -30 °C to 70 °C
	Humidity: 95% Non-Condensing
	Electrostatic Discharge: Contact Discharge ±8KV, Air Discharge ±12KV
	OVP: Threshold 12V
	EOS: VBUS 300/80us VBAT 300v/20us

Certifications	IP68
	CE
	CCC
	FCC
	ATEX Zone 2/22
	MIL-STD-810H

Data Collection	Fingerprint Power On/Off & Fingerprint 2-in-1
	Flashlight 1W
	NFC

Accessories	Hand Strap (Standard)
	33W Fast Charge Adapter (Standard)
	1.5m Type-C Cable (Standard)
	Tempered Glass Film (Optional)
	Docking Charger 5V2A (Optional)

*Product specifications, pictures, and other information are for reference only. The appearance is subject to the material object. This instruction is subject to change without notice.
