·Debian 11 OS，Maximum 4 GB of LPDDR4 RAM and 128 GB storage ·8-inch IPS screen，support 10-point capacitive touch
·Professional 2D scanner
·Support GPS+BeiDou
·Equipped with multiple
·accessories, like docking charger, hand-strap, vehicle mount, car charge, removable battery
ip65
gps
dual-battery
camera
4g
wifi
bluetooth
2D
| Basic parameters | Performance parameter | |||||||||||||||||||||
| Dimension | 274.9 x 188.7 x 22.2 mm | CPU | RK3568 | |||||||||||||||||||
| Weight | Device unit 1028 g | OS | Debian 11 | |||||||||||||||||||
| Device Color | Gray | RAM | 4GB | |||||||||||||||||||
| LCD | 10.1 inch IPS 16:10, 800×1280, 700 nits | Storage | 128GB | |||||||||||||||||||
| Touch Panel | 10 point G+G capacitive touch screen | Battery | ||||||||||||||||||||
| Camera | Front 5.0MP Rear 8.0MP | Capacity | 3.8V/10000mAh | |||||||||||||||||||
| I/O | USB 3.0 Type-A x 1, USB Type-C x 1, SIM Card x 1, TF Card x 1 (MAX 512GB), Φ3.5mm standard earphone jack x 1, DC jack x 1, HDMI x 1, 12PIN Pogo Pin x 1 | Type | Removable Li-polymer battery | |||||||||||||||||||
| Endurance | 8hrs (50% volume sounds, 50% screen brightness, 1080P HD video display by default) | |||||||||||||||||||||
| Reliability | ||||||||||||||||||||||
| Three-option interface | USB 2.0 x 1 RJ45 100M x 1 RS232 x 1 | Operate Temperature | -15 °C ~ 55 °C | |||||||||||||||||||
| Store Temperature | -30 °C ~ 70 °C | |||||||||||||||||||||
| Power | AC100V ~ 240V, 50Hz/60Hz, Output DC 5V/4A | Humidity | 95% Non-Condensing | |||||||||||||||||||
| Network connections | Rugged Feature | IP65 certified, MIL-STD-810G certified | ||||||||||||||||||||
| WIFI | WiFi 802.11 a/b/g/n/ac (2.4G+5.8G) | Drop Height | 1.22m drop | |||||||||||||||||||
| Bluetooth | BT5.0 Transmission distance: 10 m | Data Collection | ||||||||||||||||||||
| 2D | Optional, Optical resolution: 5mil/ scan speed: 50 times/s | |||||||||||||||||||||
| 2G/3G/4G | GSM：900/1800 WCDMA：B1/B5/B8 TDD：B40 FDD：B1/B3/B5/B7/B8/B20 | |||||||||||||||||||||
| GNSS | Support GPS+BeiDou | |||||||||||||||||||||
* Please be aware all technical data, specification and performance figures subject to change without notice.
·Debian 11 OS，Maximum 4 GB of LPDDR4 RAM and 128 GB storage ·8-inch IPS screen，support 10-point capacitive touch
·Professional 2D scanner
·Support GPS+BeiDou
·Equipped with multiple
·accessories, like docking charger, hand-strap, vehicle mount, car charge, removable battery
Various modules and accessories can be selected to meet customers' application in various industries.
Various modules and accessories can be selected to meet customers' application in various industries.
